Remote Monitoring and Control Single Phase Solar Pump Inverter
Place of Origin China
Brand Name VEIKONG
Certification CE
Model Number VFD500-PV
Minimum Order Quantity 1
Price Negotiable
Packaging Details the power less than 45kw use Carton, starting from 45kw use Wooden case
Delivery Time 3 days, depend on the order quantity
Payment Terms L/C, T/T, Western Union
Supply Ability 15000pcs per Month
Product Details
Product Name Solar Pump Inverter Output Type Single Phase/three Phase
Voltage 220v/380v Color Bule And White
Efficiency 99% Frequency 50/60hz
GPRS Support Remote Control PC Tool Software Support
Hybrid Mode Yes Brand VEIKONG
Original China Dry Run Protection Yes
High Light

GPRS MPPT Single Phase Solar Pump Inverter

,

IP65 PMSM Single Phase Solar Pump Inverter

,

450VDC Irrigation Solar Pump Inverter

Product Description

220v IP65 high performance Single Phase Solar Pump Inverter manufacturer​

Company info
VEIKONG is a technology company that has set new standards in the market since its inception in 2014. Our Soft Starters are exceptional products that provide safe and reliable startup for motors and other types of equipment.

Our Soft Starters are customizable, meeting varying voltage and power demands, and their energy-efficient performance, durability, and user-friendly interface set them apart from the competition. Our Soft Starters reduce equipment lifespan stress, lowering maintenance costs while extending the lifespan of the equipment.

We are committed to delivering quality service to our clients, and our Soft Starters' user-friendly interface ensures easy installation, operation, and maintenance. Our Soft Starters' robust design provides superior reliability in even the harshest conditions, providing maximum uptime for our clients' operations.

At VEIKONG, our clients are our priority. We offer personalized support to our clients, understanding and meeting their individual needs. Our Soft Starters' flexibility means we can tailor them to meet the varying requirements of our clients.

In summary, VEIKONG's Soft Starters are the perfect solution for businesses requiring safe, energy-efficient startup for their equipment. Our Soft Starters reduce electrical stress during startup, extending equipment lifespan and lowering maintenance costs. Additionally, VEIKONG's customer-centric approach ensures our clients receive expert personalized support, maximizing uptime and minimizing downtime.




Product Details and Features:



VFD500-PV Seires High Performance Solar Pump Inverter

Power range: 0.75~75kw 220V

0.75~160kw 380V



1. MPPT with 99% high efficiency

2. Driving for AC induction motor or PMSM

3. GPRS remote monitoring and control

4. Long service life working and long warranty

5. Maximum DC power input: 450VDC for 220AC output /810VDC for 380V AC output

6. Easy install and operation, no need set parameters

7. Optional LCD keypad, no need use manual

8. A variety of protection, drying runing protection, water fulling protection, overvoltage protection, overcurrent protection

9. Built in PID function, when MPPT control, PID is also enable.

10. Connect DC and AC power, inverter can work 24 hours.



Advantage

Half of the energy produced around the world is used to operate pumps. Compared to diesel generator pumps, our solar pump inverter are environmentally friendly, with a long lifetime and low maintenance costs. It is independent from the grid and produces no pollution or noise. Typical applications are irrigation, community water supply, fish farming and agriculture.



All of our drives have many solar-specific and pump control functions, such as built-in maximum power point tracking and dry run detection, as well as sensorless flow calculation.



The maximum power point tracking (MPPT) ensures you to get the best output power possible from your solar panel and it maximizes the performance of your pump along the day while the automatic start and stop with solar radiation can save money and fuel during daylight hours



VEIKONG VFD500-PV solar pumping inverter is specially designed for watering system. A high converting efficiency of 99% and advanced MPPT technology make the solar energy fully used. It converts DC power into AC to drive all kinds of motors. The intelligent design protects the pumps from many abnormal cases, such as over-loading, over-voltage, dry-running, over-heating,low frequency and etc.





Electrical Specifications and Power degree



  220V 380V
Max input DC voltage 450V 810V
DC voltage range 150~450VDC 300~810VDC
Normal working DC voltage 260V-400V 400V-650V
Recommended input mppt voltage 330V 550V
MPPT efficiency >99%
Rated output voltage 1/3-phase 220VAC 3-phase 380-480VAC
Output frequency range 50/60Hz
Max efficiency of the machine 99%
Power range 220v 0.75kw to 75kw, 380v 1.5kw-160kw
Cooling method Air cooling
Protection degree IP20/IP65
Altitude Below 1000m; above 1% for every additional 100m.
Standard CE/ROHS





Product Application
Remote Monitoring and Control Single Phase Solar Pump Inverter 0

Remote Monitoring and Control Single Phase Solar Pump Inverter 1


Why chose VEIKONG?

1. Infineon brand IGBT/Fuji IGBT, enduree temperature 175°C
2. Two-lines LED keypad/LCD kaypad
3. Fan: 70 000 hours using life
4. Capacitor: 50 000 hours using life
5. Input phase lacking protection
6. Output short circuit protection
7. Overvoltage protection
9. 10 000-15 000pcs per month production ability
10. 500pcs stock below 90KW
11. CE ISO certification, TUV SGS authority
12. Strong RD department, can update software
