50/60hz IEC RFI Inlet EMI EMC Plug VFD Filter For Medical Electronic Equipment
  • 50/60hz IEC RFI Inlet EMI EMC Plug VFD Filter For Medical Electronic Equipment
  • 50/60hz IEC RFI Inlet EMI EMC Plug VFD Filter For Medical Electronic Equipment
Place of Origin China
Brand Name VEIKONG
Certification CE
Model Number VKS
Minimum Order Quantity 1
Price Negotiable
Packaging Details Carton
Delivery Time 3 days, depend on the order quantity
Payment Terms Western Union, T/T, L/C, D/A, D/P, PayPal
Supply Ability 15000pcs per Month
Product Details
Product Name EMI EMC Plug Filter Transfer Function Low Pass
3dB Bandwidth 5-10% Input Impedance 50Ω
Insertion Loss 60dB-90dB Frequency 50/60hz
High Light

EMC Plug VFD Filter

,

60hz VFD Filter

,

60hz vfd emi filter
Product Description

380v Three Phase AC EMI Filter electromagnetic interference filter


EMI Power Line Filter from the LC low-pass passive network components.It uses principles of impedance mismatch,so that by
the attenuation of electromagnetic interference signals.
Filter filtering effect depends on the extent of impedance mismatch,the greater the impedance difference, the better the
filter. For example,to get better results, for low-impedance power supply side, should be accompanied by a high input
impedance of the filter;pairs of high input impedance of the load side, then the filter with low output impedance.



Product Features



This catefory of products has superior capability of interference containment and can be applied to data processing system, telecommunication equipment inverter and power conditioning equipment that impose high requirement on interference containment.



Rataed Voltage: AC 380V-440V

Test Voltage (1minute): Phase to Phase DC 1500V; Phase to Ground AC 1500V / DC 2500V

Operating Frequency: 50/60HZ

Range of temperature: -25-85℃

Insulation Resistance: Phase to ground (up to 300A) ≥ 1500MΩ





Model Low Pass EMI Filter
Transfer Function Low Pass
Package Type Surface Mount
Nominal Center Frequency 10K-30MHZ
Insertion Loss 60~90dB
Input Impedance 50Ω
Rated Voltage 380V/440V
Rated Current 1A-100A
Environmental Temperature 40°C
Temperature Range 25 / 085 / 21
Operating Frequency 50/60HZ
Line to Line 1450VDC
Line to Ground 2250VDC or 2000VAC
Maximum Leakage Current 115VAC/60HZ 1.4mA Max. 250VAC/60HZ 2.5mA Max
MOQ 5pcs
Price USD60~80/Meter
Lead Time 5~15 weekday for Low Pass EMI Filter



50/60hz IEC RFI Inlet EMI EMC Plug VFD Filter For Medical Electronic Equipment 050/60hz IEC RFI Inlet EMI EMC Plug VFD Filter For Medical Electronic Equipment 1



Our Advantages



1. After years of efforts of the company's personnel, products successively obtained the cUL,
TUV,CQC, CE, ROSH certifications.

2. We have a professional R&D team; our aims is we won't let customers spend any extra money!

3. National high-tech enterprises, brand assurance, reliable quality, and we have the relevant

product certifications.

4. We cooperate with top scientific research laboratories to provide free EMC rectification technical

support, samples; and free conduction test.

5. Automation technology, scale production, great price,excellent, service, fast delivery! Free replacement

within three months, free maintenance within six years, life-long maintenance!



Low leakage current to meet with medical machine special requirements.
Applicable to suppressing noise and high frequency harmonic in power.
Low leakage current with high insert lose of noise.
Control EMI interference between line and line,line and ground.
Available for electronic equipments and measuring instruments.



50/60hz IEC RFI Inlet EMI EMC Plug VFD Filter For Medical Electronic Equipment 250/60hz IEC RFI Inlet EMI EMC Plug VFD Filter For Medical Electronic Equipment 3







Characteristics

(1) Voltage Rating............................................................................................115/250VAC

(2) Current Rating:

A.@115VAC............................................................................................... 60A RMS Max.

B.@250VAC............................................................................................... 60A RMS Max.

(3) Oprating Frequency:50/60Hz

(4) Leakage Current: each line to ground

A. 115VAC/60Hz........................................................................................... 5mA Max.

B. 250VAC/50Hz...........................................................................................10mA Max.

(5) Hipot Rating(for one minute)

A. Line to ground............................................................................................ 2250VDC

B. Line to line.................................................................................................. 1450VDC

(6) IR: 50M ohm A7 500VDC any input or output to ground

(7) Temperature Range: -25℃~+85℃
