Advanced Single Phase Solar Pump Inverter 220V 0.75KW 1HP 1.5KW 2HP for Solar Water Solutions
Place of Origin China
Brand Name VEIKONG
Certification CE
Model Number VFD500-PV
Minimum Order Quantity 1
Price Negotiable
Packaging Details the power less than 45kw use Carton, starting from 45kw use Wooden case
Delivery Time 3 days, depend on the order quantity
Payment Terms L/C, T/T, Western Union
Supply Ability 15000pcs per Month
Product Details
Product Name 2.2kw Single Phase Inverter Voltage 220v
Power 0.75kw/1.5kw Horsepower 1hp/2hp
Keypad LED And LCD Warranty 18 Monthes
Brand VEIKONG MPPT Efficiency More Than 99.9999%
Highlight

99% Single Phase Solar Pump Inverter

,

Inverter For 1hp Submersible Pump

,

Single Phase Solar Pump Inverter 1hp

Product Description

Mppt efficiency 99% solar pump inverter 220v 0.75kw 1hp 1.5kw 2hp



Model Range



Drive Model Related Voltage Max DC input voltage (V) Rated output current (A) Applicable water pump (KW) SIZE
VFD500M-20T00150-PV 220V 800 7 1.5 SIZE A
VFD500M-20T00220-PV 220V 800 10.6 2.2 SIZE A
VFD500M-40T00150-PV 380V 800 4.2 1.5 SIZE A
VFD500M-40T00220-PV 380V 800 6 2.2 SIZE A
VFD500-20T00150-PV 220V 800 7 1.5 SIZE A
VFD500-20T00220-PV 220V 800 10.6 2.2 SIZE A
VFD500-20T00400-PV 220V 800 17 4 SIZE A
VFD500-40T00150-PV 380V 800 4.2 1.5 SIZE A
VFD500-40T00220-PV 380V 800 6 2.2 SIZE A
VFD500-40T00400-PV 380V 800 9.4 4 SIZE A
VFD500-40T00550-PV 380V 800 13 5.5 SIZE B
VFD500-40T00750-PV 380V 800 17 7.5 SIZE B
VFD500-40T01100-PV 380V 800 25 11 SIZE C
VFD500-40T01500-PV 380V 800 32 15 SIZE C
VFD500-40T01850-PV 380V 800 38 18.5 SIZE D
VFD500-40T02200-PV 380V 800 46 22 SIZE D
VFD500-40T03000-PV 380V 800 60 30 SIZE E
VFD500-40T03700-PV 380V 800 75 37 SIZE E
VFD500-40T04500-PV 380V 800 96 45 SIZE F
VFD500-40T05500-PV 380V 800 112 55 SIZE F
VFD500-40T07500-PV 380V 800 150 75 SIZE G
VFD500-40T09000-PV 380V 800 176 90 SIZE G
VFD500-40T11000-PV 380V 800 210 110 SIZE H
VFD500-40T13200-PV 380V 800 253 132 SIZE I
VFD500-40T16000-PV 380V 800 304 160 SIZE I
VFD500-40T18500-PV 380V 800 340 185 SIZE J
VFD500-40T20000-PV 380V 800 377 200 SIZE J





Key Advantages:



1, The power range is from 220V 0.75kw to75kw, and 380v 0.75kw to 160kw



1, MPPT control mode, adjust the output frequency to the appropriate frequency in real-time.



2,,Adjust water outflow of pumps quickly on basis of sunlight intensity change.



3,With functions of light weak protection, dry run and low voltage,full water warning, overvoltage and overtemperature protection.



4, New keyboard design, support optional LCD keypad, simple appearance, and easy operation.



5,Automatic running without any commisioning in keypad control and GPRS monitoring option(as option).



6,Support PMSM pump





Techincal Parameters:



1. Wake up and sleep function parameters:



P47.05 Light detection threshold If the output frequency is lower than this value and exceeds P47.06, it will be reported to Sleep and stop 0Hz
P47.06 Light detection time See P47.05 for explanation. 60s
P47.07 Light weak wake up time After the sleep fault is reported, if the time when Vdc is higher than the undervoltage point is greater than the set value, the fault state is exited and the operation continues. 600s



2. Dry runing protection function parameters:



P24.12 Dry run/Unload protection option

0: No offload detection is performed;

1: Enable dry run detection

1
P24.13 Dry run/Unload detection level

0.0 to 200.0%

The percentage of motor rated current.

0.0%
P24.14 Dry run Unload detection time 0.000s~60.000s 30.000s
P24.15 Unload detection offset frequency

0.00Hz~Fmax

Detection frequency=Fmax-P24.15



5.00Hz
P24.16 Reset time of dry run protection 0.0~6000.0 240.0s
P23.21 Dry run detection mode

0000:Coast stop

1000:Fast stop

3000:Continue to run

0000



3. Water full protection function parameters:



P47.18 Full water level detection channel

0:ineffective

1:AI1

2:AI2

3:AI3

4:AI4

Note: DI terminal function code 60-full water level detection is same with Analogue detection, and the detection time and recovery time are the same.

0
P47.19 Full water level detection value

0.0~100.0%





0.0%
P47.20 Full water level detection time

0.0~3000.0s

When DI-60 is valid or meets the analog detection channel greater than P47.19 and maintains P47.20 time, the system reports A.Full and stops.



10.0s
P47.21 Full water recovery time

0.0~3000.0s

When the condition described in P47.20 does not meet full water level detection requirement ,it will be returned to normal state after delay

10.0s





Support optional LCD keypad

LCD display



Support optional GPRS Module

Advanced Single Phase Solar Pump Inverter 220V 0.75KW 1HP 1.5KW 2HP for Solar Water Solutions 1


Product application pictures

Advanced Single Phase Solar Pump Inverter 220V 0.75KW 1HP 1.5KW 2HP for Solar Water Solutions 2

Advanced Single Phase Solar Pump Inverter 220V 0.75KW 1HP 1.5KW 2HP for Solar Water Solutions 3
